Resistive Termination DC-6GHz 2W 7-16(m) IP67

Please Register or call for more information

SKU: TA-2MD Categories: , ,

Microlab TA series terminations are low power coaxial loads, which operate from DC to up to 6 GHz depending on the model. Each has been designed with a resistive film terminating element, contained within a carefully matched coaxial housing.

Standard connectors are SMA, N, 4.3-10 and 7-16 DIN.

  • Resistive Film Load
  • 1W & 2W standard
  • VSWR to 1.15:1
  • High Peak Power
  • RoHS compliant, most to IP67
  • For wireless and general applications

Download Datasheet

Frequency: DC-6.0 Ghz
Power: 2 W
VSWR: 1.15:1 up to 2 GHz
  1.25:1 up to 4 GHz
Connectors: 7-16(m)
Ingress Protection: IP67
Weight: 0.25 lbs (113 g)
