TK-28FE


Allow Partial Shipments

Termination 350-2700MHz 200W – 161dBc 4.3-10(f) IP67

Please Login to See Price
SKU: TK-28FE Categories: , ,

Microlab TK-28 series 200W Cable Loads are intended for wireless applications, when extremely low PIM, Passive Intermodulation, is required. A typical application is terminating the unused port of a Hybrid Coupler used to combine different wireless signals. A broad frequency range of 300 to 2700 MHz covers the majority of wireless applications requiring low PIM performance.
Air flow over the load is assumed, in order to meet the rated surface temperature.

  • Very Low PIM
  • 200W average Power
  • Low VSWR
  • Intimate cable contact
  • RoHS compliant
  • Mounting Brackets included

Download Datasheet

Frequency: 300 – 2700 MHz
Power: 200 W
VSWR

1.1 @ 698 – 2700 MHz

1.2 @ 300 – 698 MHz

PIM: -161 dBc (-118 dBm), tested with 2 x 20W tones at 25°C
Connectors: 4.3-10 (f)
Ingress Protection: IP64
Weight: 12 lb., (5.4 kg) nominal
